toyterm

toyterm is a toy terminal emulator for Linux.

Features/Limitations

hardware accelerated graphics
support for SIXEL graphics
support for X11 clipboard (copying & pasting)
manual font fallback: you can specify the order of fonts for each style
support for mouse reporting
(optional) support for multiplexing
toyterm assumes UTF-8 encoding
following basic functions are TODO
- automatic font selection by integrating with fontconfig
- support for operating systems other than Linux

Usage

To install:

$ git clone https://github.com/algon-320/toyterm
$ cd toyterm
$ tic -x -o "$HOME/.terminfo/" toyterm.info
$ cargo install --path .

To enable multiplexing feature, please add "--features multiplex" to the last line.
To install the terminfo globally, please do $ sudo tic -x toyterm.info instead.

To configure:

$ mkdir -p "$HOME/.config/toyterm"
$ cp ./config.toml "$HOME/.config/toyterm"
$ $EDITOR "$HOME/.config/toyterm/config.toml"

To uninstall:

$ rm "$HOME/.terminfo/t/toyterm-256color"
$ cargo uninstall toyterm
$ rm -r "$HOME/.config/toyterm"

If you would like to remove the globally installed terminfo, please try $ sudo rm /usr/share/terminfo/t/toyterm-256color too.

Keybinding

Key	Function
Ctrl + `-`	Decrease font size
Ctrl + `=`	Increase font size
Ctrl + Shift + `c`	Copy selected text
Ctrl + Shift + `v`	Paste clipboard text
Ctrl + Shift + `l`	Clear history
Up key	Send `x1b[[A`
Down key	Send `x1b[[B`
Right key	Send `x1b[[C`
Left key	Send `x1b[[D`
PageUp key	Send `x1b[5~`
PageDown key	Send `x1b[6~`
Delete key	Send `x1b[3~`
Backspace key	Send `x7f`
Mouse Wheel	Same effect as arrow keys (Up/Down/Right/Left)
Shift + Mouse Wheel	Scroll history

If feature multiplex is enalbed:

Key	Function
Ctrl + `a`, `c`	Create a new window
Ctrl + `a`, `n`	Switch to next window
Ctrl + `a`, `p`	Switch to prev window
Ctrl + `a`, `%`	Split current pane vertically
Ctrl + `a`, `"`	Split current pane horizontally
Ctrl + `a`, `z`	Maximize current pane
Ctrl + `a`, `s`	Save current layout
Ctrl + `a`, `r`	Restore saved layout
Ctrl + `a`, `x`	Close currently focused pane
Ctrl + `a`, Up/Down/Left/Right	Focus up/down/left/right pane
Ctrl + `a`, Ctrl + Up	Move the partition up (i.e. Decrease the width of upper pane)
Ctrl + `a`, Ctrl + Down	Move the partition down (i.e. Increase the width of upper pane)
Ctrl + `a`, Ctrl + Left	Move the partition left (i.e. Decrease the width of left pane)
Ctrl + `a`, Ctrl + Right	Move the partition right (i.e. Increase the width of right pane)
Ctrl + `a`, Ctrl + `a`	Send `x01` (Ctrl + `a`)

Control Functions

toyterm aims to support the standard control functions described in ECMA-48. Some private functions, widely used by modern terminals, may be supported as well. Currently toyterm supports the following functions.

C0 functions

BS
CR
ESC
FF
HT
LF
VT

C1 functions

CSI

Control Sequences

CHA
CUB
CUD
CUF
CUP
CUU
DCH
DL
DSR
ECH
ED
EL
HVP
ICH
IL
RM
SGR
- Default: e[0m, e[m
- Bold: e[1m
- Faint: e[2m
- Blinking (slow): e[5m
- Blinking (rapid): e[6m
- Negative: e[7m
- Consealed: e[8m
- Foreground Black, Red, Green, Yellow, Blue, Magenta, Cyan, White: e[30m..e[37m
- Foreground Black, Red, Green, Yellow, Blue, Magenta, Cyan, White (Bright): e[90m..e[97m
- Foreground Default: e[39m
- Foreground Gaming: e[70m
- Foreground RGB: e[38;2;{R};{G};{B}m
- Foreground 256 color: e[38;5;{idx}m
- Background Black, Red, Green, Yellow, Blue, Magenta, Cyan, White: e[40m..e[47m
- Background Black, Red, Green, Yellow, Blue, Magenta, Cyan, White (Bright): e[100m..e[107m
- Background Default: e[49m
- Background Gaming: e[80m
- Background RGB: e[48;2;{R};{G};{B}m
- Background 256 color: e[48;5;{idx}m
SM
VPA
SetScrollRegion (DECSTBM): e[{top};{bottom}r
SelectCursorStyle:
- Default (Block): e[0 q
- Block: e[2 q
- Underline: e[4 q
- Bar: e[6 q

Device Control Function

DCS q (sixel string...) ST
- see https://www.vt100.net/docs/vt3xx-gp/chapter14.html for the representation

Other Sequences

SaveCursor (DECSC): e7
RestoreCursor (DECRC): e8

Modes

toyterm supports the following modes.

Cursor Visible Mode (?25)
- Set: cursor is visible.
- Reset: cursor is invisible.
Sixel Scrolling Mode (?80)
- Set: a sixel image is displayed at the current cursor position.
- Reset: a sixel image is displayed at the upper left corner of the screen.
Normal Mouse Tracking (?1000)
- Set: enable sending mouse report
- Reset: disable sending mouse report
SGR Extended Mode Mouse Tracking (?1006)
- Set: enable SGR extended mode mouse tracking, change response of mouse click
- Reset: disable SGR extended mode mouse tracking
Alternate Screen Buffer Mode (?1049)
- Set: clear the screen, save the cursor position, and switch to the alternate screen.
- Reset: restore the saved cursor position, and switch back to the primary screen.
Bracketed Paste Mode (?2004)
- Set: insert x1b[200~ at the beginning and x1b[201~ at the end of a pasted text.
- Reset: a pasted text is send to the terminal as if it was typed by user.
